G80 Shortening Hook
The G80 Shortening Hook is a forged alloy steel component designed to adjust and shorten the effective length of chain slings. Manufactured from Grade 80 quenched and tempered steel, it meets EN 1677-1 requirements and is CE marked for safe use in lifting operations.
This hook features a robust clevis or eye design with a deep chain pocket that ensures secure grip without reducing the chain’s working load limit (WLL). It allows precise load control, making it ideal for lifting applications where chain length adjustment is necessary.
Each hook is proof-tested and permanently marked with WLL, size, and traceability code, ensuring compliance and reliability. Finished in high-visibility red, the G80 Shortening Hook provides strength, safety, and ease of use in demanding conditions.
Key Features:
-
Material: Grade 80 alloy steel (quenched & tempered)
-
Standard: EN 1677-1, CE marked
-
Design: Deep chain pocket for secure shortening
-
Finish: Powder-coated in safety red
-
WLL Range: Suitable for chain sizes 6 mm to 32 mm
-
Safety Factor: Minimum 4:1
-
Markings: WLL, size, traceability code
Benefits:
-
Enables easy adjustment of chain sling length
-
Maintains full chain WLL when used correctly
-
Strong, durable, and impact-resistant construction
-
Certified and tested for heavy-duty lifting applications
Applications:
Widely used in construction, shipbuilding, steel industry, ports, and heavy logistics where safe and adjustable lifting configurations are required.
